NSMB - 2022 - Hardtail Thread...

Oct. 7, 2022, 10:14 p.m.
Posts: 1461
Joined: March 16, 2017

Posted by: Vikb

First ride in 6 weeks after breaking my toe. Shorts/t-shirt and dusty trails. My calendar says it's October, but it sure doesn't feel like it! Now to build fitness and avoid further injuries.

Jealous of your injury recovery I readily admit.

Oct. 8, 2022, 10:52 a.m.
Posts: 2383
Joined: Sept. 10, 2012

Posted by: Endurimil

Jealous of your injury recovery I readily admit.

I flipped back and forth between feeling sorry for myself not being able to much sporty stuff the last 6 weeks and appreciating, that while it was annoying, it was a minor injury in the great scheme of things.

Oct. 8, 2022, 10:58 a.m.
Posts: 2383
Joined: Sept. 10, 2012

Did another local XC hardtail ride this morning. Nice to be riding with my GF instead of having her tell me what the trails are like after she goes riding. One downside to having most of my social interactions setup around sporty activities is that when I'm injured I feel pretty unplugged. Terrible timing as I missed 4 sweet trips/events with amazing weather, but $hit happens. I'm just happy to be rolling on dirt again.

Oct. 8, 2022, 1:34 p.m.
Posts: 1461
Joined: March 16, 2017

Posted by: BC_Nuggets

Posted by: [email protected]

Good thing that these days we have an abundance of choice in reliable droppers of all lengths to cover all possible combinations of body shape, bike geo and riding style! ;-)

Except if you don't have internal routing for dropper.  Where's the affordable wireless technology?

There isn't a dropper for no internal routing. Weird....

Oct. 8, 2022, 6:41 p.m.
Posts: 535
Joined: Jan. 21, 2013

Posted by: BC_Nuggets

I also want to shorten my seat tube (can maybe do between half to full inch) but might not need to since internal posts have lower stack height than external.

The stealth dropper drilling is as tashi said. I do two holes, just about touching - and finish up by either wiggling the bit to connect or filing/dremel tooling them into one oval.

Drill bit size is ~5mm (if you have metric bits) or so. A 1/4” bit is closer to 6mm and that works too. The tip to centre punch first is a good one especially if it’s steel so the bit doesn’t walk.

I avoid drilling within 1” of a weld but I’m not sure if that’s necessary. I could be wrong but it seems like the metal is more brittle there from the heat during the weld.

Cutting a seat tube is much the same thing. Measure the length of the slot in the seat tube to start. If you deviate too much from that length the seat tube can have a hard time clamping the seat post. Drill a hole at the end and then use an angle grinder to connect the slot to the hole. I cut my last aluminum one with a pipe cutter and faced it up with a 60 grit flap disc on a grinder but a file could do the same thing. Last steel frame I cut I used a sawzall with a hacksaw bit.

Parts store touch up paint (in a shade close to yours) covers up the exposed edges on a steel frame nicely

Good luck! Just go for it. Plumbers and electricians cut tubing like this for pipes or conduit literally all day so the tools are easily found at any hardware store if you’re missing anything.

Oct. 13, 2022, 1:44 a.m.
Posts: 112
Joined: Jan. 18, 2019

I've drilled holes for droppers in both alum' and steel.

4mm bit straight in and GENTLY worked vertically back and forth to ovalize the hole and it takes a standard gear cable housing perfectly. You'll need to put the housing end cap on from the top of the seat tube cos the hole is so snug.

Be brave. Do it!

Oct. 13, 2022, 10:41 a.m.
Posts: 1065
Joined: May 11, 2022

Posted by: Endurimil

Posted by: BC_Nuggets

Posted by: [email protected]

Good thing that these days we have an abundance of choice in reliable droppers of all lengths to cover all possible combinations of body shape, bike geo and riding style! ;-)

Except if you don't have internal routing for dropper.  Where's the affordable wireless technology?

There isn't a dropper for no internal routing. Weird....

LOL.  Yeah there's still some choices out there.  Not a lot though.  Still might drill a hole to expand my options.  Thanks everyone!

Oct. 17, 2022, 7:10 a.m.
Posts: 2383
Joined: Sept. 10, 2012

I've been out enjoying the unseasonably warm/sunny/dry conditions making up for lost riding time. Trails are dry and dusty in a way my brain can't correlate with it being mid-October. I managed to finally get a flat after so long I can't recall when the last one happened, but it was at least a couple years ago now. I landed on something sharp off a small drop and put a hole in the tire mid-tread. Small enough it didn't want to eat some bacon. Big enough it didn't want to seal right away. I put something like 8 psi in the tire and rode home out of the trails on a soft tire + Tannus insert with no issues. Since I had to ride home from the trails I put a bit more air into the tire for the pavement and rolled home.

I've got some fresh winter rubber for the bike I'll put on today. I'll repair the old tire with a patch on the inside and keep it as a back up.

Although getting a flat is slightly annoying it's great that I can ride so much on current tire/insert/rim tech with exceedingly few flats and no rim damage. Particularly on the rear of a hardtail.

Oct. 17, 2022, 4:13 p.m.
Posts: 1065
Joined: May 11, 2022

Posted by: Vikb

I've been out enjoying the unseasonably warm/sunny/dry conditions making up for lost riding time. Trails are dry and dusty in a way my brain can't correlate with it being mid-October.

Yeah!  Is it just me or is the dirt more slippery and the roots more grippy than they should be?  ;)

Oct. 17, 2022, 7:21 p.m.
Posts: 310
Joined: May 1, 2018

If you’re drilling a seat tube I’d consider:

- the lowest stress / strongest place to drill is the BB shell itself, so if you’re running a configuration where you can route around the bb and spindle (zero contact or you’ll wear the spindle, a centre sleeve to protect is probably a must), do it that way.

- mock up the bend. If it’s in a bad place you won’t be able to undrill.

- don’t drill opposite bottle cage bosses or anything else applying stress to frame.

- centre punch is a great start.

- low speed drill. A pilot hole with a 2mm will be a big help.

- 20-30mm from bottom of tube should be enough to avoid compromising but also still be in the thicker butt rather than the thin central part of the tube. Depending on your frame manufacturer they might actually have the tube spec which would be helpful. Knowing where the butts are is really helpful, I recommend it.

- if it’s steel, use some sugru / kintsuglue / silicone sealant once installed so you can keep water out of the tube. Some nail polish or paint is a good idea.

- if it’s not steel or Ti then it’s probably going to shorten it’s life span drilling it.

- AXS 🫤


 Last edited by: Heinous on Oct. 17, 2022, 7:22 p.m., edited 1 time in total.
Oct. 17, 2022, 7:56 p.m.
Posts: 833
Joined: Feb. 24, 2017

Took my hardtail out for a mini bikepacking trip. Taking the 'use the gear you have' approach and picking a super easy ride to test the suitability for the offspring.

All the gear, no idea.

All the gear, no idea.

Bedtime

First night in the valley.

Into the clouds

Up into the clouds for a damp second evening. I tried a lightweight sleeping suggestion from a buddy - down jacket + kids sleeping bag up to my ribs.

I've slept warmer in snow caves. Would be fine in a hut, but for single digit °C in a tent not recommended.

Coffee and sunshine

Sunshine with coffee, and a Vogels bag to tease the expats.

The hill. Side two

The hill, side two

Stopping to boil water after running out.

Fun trip, with a bit of editing it should work for the 5&7 year olds, or editing the other way for a tougher funner groan up version.


 Last edited by: velocipedestrian on Oct. 17, 2022, 8:16 p.m., edited 1 time in total.
Oct. 18, 2022, 5:03 a.m.
Posts: 1463
Joined: Aug. 13, 2017

Velo - where was your bike packing trip?

Oct. 18, 2022, 6:04 a.m.
Posts: 2383
Joined: Sept. 10, 2012

Posted by: velocipedestrian

Took my hardtail out for a mini bikepacking trip. Taking the 'use the gear you have' approach and picking a super easy ride to test the suitability for the offspring.

Up into the clouds for a damp second evening. I tried a lightweight sleeping suggestion from a buddy - down jacket + kids sleeping bag up to my ribs.

I've slept warmer in snow caves. Would be fine in a hut, but for single digit °C in a tent not recommended.

Looks like fun. I'm glad you got out camping with your bike. I've been through quite a few cold nights myself chasing the elusive light/compact sleep setup that is still comfortable. I mostly have it figured out now so good sleep is on the menu, but there was certainly some pain for that gain.

Let us know how the kids like the route.

Oct. 18, 2022, 6:09 a.m.
Posts: 2383
Joined: Sept. 10, 2012

Posted by: BC_Nuggets

Yeah!  Is it just me or is the dirt more slippery and the roots more grippy than they should be?  ;)

Ha! It's amazing how many times in one ride you can be surprised by loose dusty corners in October. We've got some rain in the forecast so at least it won't feel like summer riding any more.

Oct. 18, 2022, 9:30 a.m.
Posts: 1065
Joined: May 11, 2022

Rant:

My technical climbing is absolutely garbage this past year.  I'm spinning out, wheelie-ing out, chickening out, crashing out in attempts to do stuff I could previously climb.  I don't think much has changed on my bike.  I'm back on a longer stem which has helped but I don't know what the hell else is going on.  Maybe having an ikon 2.35 on the back isn't the best idea.  And maybe it's the dry and dusty conditions?  My bar is a little higher now but it won't go lower and overall it's super comfortable.  It's definitely a combination of psychology and perhaps my core and upper body strength has declined.  I know hardtails are a bit harder to climb on the more technical, slippery stuff than FS but the stuff I'm having problems with isn't THAT bad.  Perhaps I'm choosing too easy of a gear, not coming in with enough momentum, not being explosive when required.  I don't know...it's just sad.

Guess I just need to keep working on it.  It's one thing to be stuck and not improving but in this particular area I have gotten worse and I can't put a finger on why besides it's likely a combination of several factors.

Thanks for listening.  Ah...feels a little better now.
